Wireless Air Velocity Vane Probe. Use with Your Smart Phone & FREE TPI View App to display air velocity, CFM, and temperature readings.

The SP555 is a vane velocity Smart Probe. It measures air velocity and temperature; calculates CFM (Volume); connects to mobile device and uses the TPI View App. Perform average air velocity and air volume tests. 3 Year Limited Warranty

Features:

Measure air velocity and temperature simultaneously
Communicate with smartphone using Bluetooth LE and TPI View App
Record minimum, maximum & average readings
Multiple measuring units: m/s, km/h, ft/min, knots, mile/h
Automatically calculates and displays CFM through the View app

Applications:

Air velocity measurements in HVAC systems
Air duct analysis to balance commercial and residential HVAC systems
Fume hoods
Floor registers
Exhaust grills

£80.00
RRP exc. VAT

TPI View App

TPI View App
Smart phone app allows easy documentation that you can share with your customer. Reduce paperwork and save time!

Use your smartphone to interact with TPI’s Smart Devices. Job Management allows you to create multiple JOBS and attach multiple REPORTS to each Job! Give each report a different reference/name; save to an existing JOB or create a NEW one! Learn More

Documentation

Click to view or download product PDFs

SP555 Product Sheet

SP555 Manual

SP555 CE_EU_Rep

Specifications

SP555 Wireless Air Velocity Probe Specifications
Range	98 fpm ~ 4900 fpm (0.5 m/s ~ 25 m/s) -4°F ~ 140°F (-20°C ~ 60°C)
Resolution	2 fpm (0.1 m/s) 0.1°F / 0.1°C
Air Velocity Accuracy	± ( 2% of mv + 59 fpm) ± ( 2% of mv + 0.3 m/s)
Temperature Accuracy	±1°F( 32°F ~ 113°F ) / ±2°F ( -4 °F ~ 31.9°F, 113.1°F ~ 140°F ) ±0.5°C( 0°C ~ 45°C ) / ±1°C ( -20°C ~ -0.1°C, 45.1°C ~ 60°C ) +/-0.02 inH2O (0 to 1 inH2O) / +/-(1.5% + 20 digits) (> 1 inH2O)
Operation Temperature	-4°F ~ 122°F (-20°C ~ 50°C)
Storage Temperature	-4°F ~ 140°F (-20 °C ~ 60 °C)
Battery Life Time	About 30 hours
Battery Type	AAA x 3 (4.5V)
Weight	3.74 oz (106 g)
