9071 Vibration Analyser
£750.00
The TPI 9071 is a simple, easy to use, low cost vibration meter. Record, analyse and display vibration signals at the push of a button.
In stock
Description
The TPI 9071 is a simple, easy to use, low cost vibration meter. Record, analyse and display vibration signals at the push of a button.
- Built-in ISO Alarms
- Find machine faults before they stop your machine
- Increase productivity and lower maintenance costs
- Full Color LED Display
- Collect data
- Standard Cable mounted accelerometer with magnet
- ISO built-in Alarms
- Easily identify bearing problems with BDU Reading
- Easily identify problems with built-in band filters:
1X (unbalance)
2X (misalignment)
3X (looseness) - 800 line FFT (spectrum)
- Ruggedized IP67 case
- 3-year Limited Warranty
Details
ANALYZE • INTERPRET • SAVE
Vibration analysis at the touch of a button!
The TPI 9071 analyzes & interprets readings: ISO machine alarms and BDU reading indicate overall machine and bearing condition; clear picture of machine problems detects imbalance, misalignment and looseness; 800-line spectrum with zoom and cursor to identify complex issues.
Collect and store test data. Storage space of 10 memory blocks with 20 readings per block available. Stored readings can be displayed for analysis.
Video
Specifications
| Â Model 9071 Specifications | ||
|---|---|---|
| Size | H 7.95″ W 2.36″ 200 mm x 60mm x 26mm | |
| Weight | 9.8oz (280g)(not including magnet) | |
| Environmental | * Water: IP67 Waterproof * Operating: 32°F to 122°F (0°C to 50°C) * Storage: -4°F to 158°F (-20°C to 70°C) |
|
| Power Supply | 2xAA batteries | |
| Battery Life | Approximately 50 hours of normal use | |
| Frequency Ranges | 2/10Hz – 1kHz ISO 2Hz – 10kHz Total g 1kHz – 10kHz Bearing Analysis |
|
| Frequency Resolution | 100 / 800 lines | |
| Displayed Amplitude Units | Acceleration in g Velocity in inches per second or mm per second Bearing Damage in BDU |
|
| Displayed Frequency Units | Hz, CPM or RPM | |
| Input Range | +/- 50 g (with supplied accelerometer) | |
| Dynamic Range | 72 dB (0.05g resolution) | |
| Auto set up of VA bands | Yes | |
| Measurement Storage | 10 blocks / 20 readings per block | |
| Accelerometer Connection | BNC connector cable with removable magnet (1mV/g – 10,000mV/g) | |
| Reading Storage | 10 blocks/ 20 readings per block | |
| Standard Accessories | A9012 IEPE accelerometer with cable A9073 magnet A9074 Soft pouch |
|
| Optional Accessories | A9086 Protective boot with magnets | |
